D-Link DHP-307AV
PowerLine AV Network Starter Kit

D-Link DHP-307AV

Sorry, this product is no longer available, please contact us for a replacement.


Overview:

The DHP-307AV instantly transforms your home's existing electrical wiring into a high-speed network.

Use Existing Wiring to Create a Home Network
The D-Link PowerLine AV Network Starter Kit (DHP-307AV) allows you to create or expand your home network using your existing electrical wiring2. By simply attaching one adapter from your router into your existing electrical system, you can turn every power outlet into a possible network connection2.

Expand Your Network Without Running Wires
D-Link PowerLine AV Network Adapter technology extends your network's range by utilizing your home's existing electrical wiring2. This device is also ideal for homes or small offices where concrete walls, successive floors in multi-storied buildings, or other architectural impediments could inhibit a wireless signal. Connect multiple devices in the farthest corners of your home by attaching a switch or wireless access point to a D-Link PowerLine AV Network Adapter.

Conveniently Connect
D-Link's PowerLine AV Network Adapter transmits data reliably by intelligently adapting to the strongest signal channels. With increased speeds of up to 200Mbps1 and utilizing QoS technology, D-Link's PowerLine AV Network Adapter are ideal for streaming HD video, intense online gaming, and VoIP calling. Plus, D-Link's PowerLine AV Network Adapter incorporate 128-bit AES encryption for securing your connection to help keep your data safe from intruders.

With hassle-free plug & play installation, D-Link's PowerLine AV Network Starter Kit (DHP-307AV) is an ideal solution to create a wall-to-wall home network.

Homeplug AV Benefits

  • Speeds up to 200Mbps1
  • Stream HD content across your network
  • Connect multiple computers, game consoles, and multimedia devices to the Internet
  • QoS support helps prioritize audio & video streaming to your Digital Media Player
  • Expand your wireless LAN by connecting an access point to achieve stronger wireless signals in remote areas
  • Supports secure encryption for enhanced network security
  • Simple plug & play installation
1 Maximum throughput based on theoretical transmission PHY rate. Actual data throughput will vary. Network conditions and environmental factors, including volume of traffic and network overhead, may lower actual data throughput rate. Interference from devices that emit electrical noise, such as vacuum cleaners and hair dryers, may adversely affect the performance of this product. This product may interfere with devices such as lighting systems that have a dimmer switch or a touch-sensitive on/off feature or short wave radios.
2 Power outlets and electrical wiring must all be part of the same electrical system. Certain electrical conditions in your home, such as wiring condition and configuration, may affect the performance of this product. Additional PowerLine HD adapters required to add new devices to the network. Connecting this product to a power strip with a surge protector may adversely affect the performance of this product. For best results, plug adapter directly into a power outlet.

Technical Specifications:

D-Link DHP-307AV Specifications
Standard
  • IEEE 802.3
  • IEEE 802.3u
  • HomePlug AV
Powerline Interface Power plug
Ethernet Interface 10/100BASE-TX Ethernet Port
MDI/ MDIX RJ-45 Connector
Powerline Modulation Scheme OFDM Symbol Modulation
Data Rate Powerline: 200Mbps (PHY rate)1
QOS Integrated QOS prioritizes media and data
Security
  • 128-bit AES Data Encryption
  • Simple Connect Button
Minimum System Requirements (For PC Utility Software)
  • PC with 200MHz processor
  • 64MB memory
  • Windows 7, Vista, XP SP3
  • Ethernet interface (100Mbps)
LEDs
  • Power
  • Powerline
  • Ethernet
Power Input 100~240 VAC, 50/60Hz
Power Saving
  • Power saving mode supported
  • Compliant with European Energy Using Product Directive
Operating Temperature 30° to 104°F
Operating Humidity 10% to 95% non-condensing
EMC Certifications
  • FCC part 15 Class B
  • CE EMC Class B
Safety Certifications
  • UL
  • CE LVD
Dimensions Item (WxDxH): 2.75" x 4" x 1.6"
Packaging (WxDxH): 10.75" x 8.25" x 4"
Weight Item: 0.24 lb (per adapter), Kit: 0.48 lb
Packaging: 1.38 lb
1 Maximum throughput based on theoretical transmission PHY rate. Actual data throughput will vary. Network conditions and environmental factors, including volume of traffi c and network overhead, may lower actual data throughput rate. Interference from devices that emit electrical noise, such as vacuum cleaners and hair dryers, may adversely affect the performance of this product. This product may interfere with devices such as lighting systems that have a dimmer switch or a touch-sensitive on/off feature or short wave radios.

Product specifi cation, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted on the package herein. See inside package for warranty details. D-Link PowerLine AV Network Adapters (DHP-306AV, DHP-307AV) may coexist with, but are not compatible or interoperable with D-Link PowerLine HD Ethernet Adapters (DHP-302, DHP-303). This product is designed for use in the United States of America. Sale or use of this product in countries other than the USA might violate local laws.
