D-Link DCS-5020L
Pan & Tilt Wi-Fi Camera

D-Link DCS-5020L

Sorry, this product is no longer available, please contact us for a replacement.

Overview:

View more, do more and protect more with the clarity and mobile control of D-Link’s Pan & Tilt Wi-Fi Camera (DCS-5020L) and monitor your home or business – anywhere, anytime – on your smartphone or tablet. Experience confident clarity and total control with the ultra-smooth pan & tilt and digital zoom functionality. Integrated sound and motion-sensing with night-vision technology provides around-the-clock surveillance. With simple installation, you’ll have an effective, affordable home or business surveillance solution up and running in no time.

Connect to More

With sharp, responsive pan & tilt movement, the DCS-5020L gives you full control, so you can quickly scan a wide area from a variety of angles and 4x digital zoom lets you zoom in for more detail. Why wait for a costly technician to install your system? With the Pan & Tilt Wi-Fi Camera, installation is fast, easy, and flexible. The built-in Wi-Fi extender provides a convenient way to expand your wireless network. Placing the camera within your current network area expands your Wi-Fi signal, providing effortless connectivity to more rooms and more devices, making dead zones a thing of the past. Whether you’re looking for a superior home surveillance solution or a versatile way to monitor your small business, D-Link’s DCS-5020L lets you see more of what matters.

Convenient Access Anytime, Anywhere with mydlink®

Enhanced with mydlink® support, the Pan & Tilt Wi-Fi Camera makes it easy and convenient for you to look after your family, pets, home or small business. With a mydlink enabled camera, you can stay connected to everything you love from anywhere, anytime. Access your camera through the mydlink website or one of the mydlink mobile apps to view and manage your camera through your desktop, laptop, tablet or mobile phone, no matter where you are.

Features

Premium Resolution and Visibility

Pan & tilt function to see a wider area
See up to 26 feet in complete darkness with built-in IR LEDs
Supports H.264/M-JPEG video codecs
4x digital zoom for close-up viewing
Built-in microphone

Security

Sound & motion detection triggers e-mail/push alert notifications
Save snapshots/video clips to your mobile device

Ease of Use

Uses the Wireless N technology so you can install the camera anywhere with ease
WPS support for easy wireless connection
Extender mode for expanding wireless range

Convenient Control with mydlink® Support

mydlink app support for iPhone, iPad, Android and Windows phone
mydlink portal for easy viewing and management

Technical Specifications:

D-Link DCS-5020L Specifications
Networking Protocol IPV4, ARP, TCP, UDP, ICMP DHCP Client NTP Client (D-Link) DNS Client DDNS Client (Dyndns and D-Link) SMTP Client FTP Client HTTP Server PPPoE UPnP Port Forwarding LLTD Built-In Protocol 10/100 BASE-TX Fast Ethernet 802.11b/g/n WLAN Wireless Connectivity 802.11b/g/n Wireless with WEP/WPA/WPA2security WPS Wireless Transmit Output Power (Typical) 11b - 16 dbm 11g/11n - 12 dbm SDRAM 64 MB Flash Memory 8 MB Reset Button Reset to factory default Video Codecs H.264 MJPEG JPEG for still images Video Features Adjustable image size and quality Time stamp and text overlay Flip and Mirror Resolution 640 x 480 at up to 30 fps 320 x 240 at up to 30 fps 160 x 112 at up to 30 fps Lens Focal length: 2.2 mm, F2.0 IR LED 8 meter illumination distance with 10 LEDs and light sensor Viewing Angle Horizontal: 66.2° Vertical: 49.08° Diagonal: 77.04° Pan/Tilt Range Pan Range: +170° ~ -170° (Total 340°) Tilt Range: +95° ~ -25° (Total 120°) Digital Zoom Up to 4x 3A Control AGC (Auto Gain Control) AWB (Auto White Balance) AES (Auto Electronic Shutter) Power Input: 100-240 V AC, 50/60 Hz Output: 12 V DC, 1 A Dimensions Camera Only - 102.35 x 101.27 x 133.6 mm(4.03 x 3.99 x 5.26 inches) Camera Including Mounting Bracket -102.35 x 101.27 x 230.0 mm(4.03 x 3.99 x 9.06 inches) Max Power Consumption 8.64W Operation Temperature 0 ˚C to 40 ˚C (32 ˚F to 104 ˚F) Storage Temperature -20 ˚C to 70 ˚C (-4 ˚F to 158 ˚F) Certifications FCC Class B CE CE LV D C-Tick

D-Link DCS-5020L Specifications

Networking Protocol

IPV4, ARP, TCP, UDP, ICMP
DHCP Client
NTP Client (D-Link)
DNS Client
DDNS Client (Dyndns and D-Link)
SMTP Client
FTP Client
HTTP Server
PPPoE
UPnP Port Forwarding
LLTD

Built-In Protocol

10/100 BASE-TX Fast Ethernet
802.11b/g/n WLAN

Wireless Connectivity

802.11b/g/n Wireless with WEP/WPA/WPA2security
WPS

Wireless Transmit Output Power (Typical)

11b - 16 dbm
11g/11n - 12 dbm

SDRAM

64 MB

Flash Memory

8 MB

Reset Button

Reset to factory default

Video Codecs

H.264
MJPEG
JPEG for still images

Video Features

Adjustable image size and quality
Time stamp and text overlay
Flip and Mirror

Resolution

640 x 480 at up to 30 fps
320 x 240 at up to 30 fps
160 x 112 at up to 30 fps

Lens

Focal length: 2.2 mm, F2.0

IR LED

8 meter illumination distance with 10 LEDs and light sensor

Viewing Angle

Horizontal: 66.2°
Vertical: 49.08°
Diagonal: 77.04°

Pan/Tilt Range

Pan Range: +170° ~ -170° (Total 340°)
Tilt Range: +95° ~ -25° (Total 120°)

Digital Zoom

Up to 4x

3A Control

AGC (Auto Gain Control)
AWB (Auto White Balance)
AES (Auto Electronic Shutter)

Power

Input: 100-240 V AC, 50/60 Hz
Output: 12 V DC, 1 A

Dimensions

Camera Only - 102.35 x 101.27 x 133.6 mm(4.03 x 3.99 x 5.26 inches)
Camera Including Mounting Bracket -102.35 x 101.27 x 230.0 mm(4.03 x 3.99 x 9.06 inches)

Max Power Consumption

8.64W

Operation Temperature

0 ˚C to 40 ˚C (32 ˚F to 104 ˚F)

Storage Temperature

-20 ˚C to 70 ˚C (-4 ˚F to 158 ˚F)

Certifications

FCC Class B
CE
CE LV D
C-Tick

Documentation:

Download the D-Link DCS-5020L Datasheet (PDF).
